Pratissoli MW Series Triplex Plunger Pumps

Features:

• Max. Inlet Pressure: 45 psi

• Max. Fluid Temperature: 140° F

• Inlet Port Thread: 2″ NPT-F (MW32, 36,40); 66mm flange (MW45, 50, 55)

• Discharge Port Thread: 1″ NPT-F (MW32, 36,40); 1¼” NPT-F (MW45, 50, 55)

• Shaft Diameter: 1.969″ / 50 mm

• Pump Dimensions: 29.5″ x 23″ x 14.5″

• Crankcase Oil Capacity: 9 litres

  The MW Series Triplex Plunger Pump is available in 6 flows. The incorporated gearbox is available in 3 ratios, 1500, 1800 and 2200 rpm. It has double pressure packings, vertically fitted suction/delivery valves, splash lubrication and includes optimal drain/priming valve kit. Includes external gearbox posionable on left or right hand side of pump. Please specify RPM and gear box position when ordering.
